Nexus Magnetic Aries Series page header

Aries Series Coils

Why Builders Choose Aries
Purpose-Built Coil Platform

Aries Coil | Built for serious generator projects

The Aries Coil is designed for builders who need more than hobby-grade output. It supports larger custom generators, wind turbine experiments, battery charging setups, and off-grid prototype systems where stable performance matters. Its triangular geometry improves magnetic coupling, while heavy copper windings help reduce resistance and support dependable current handling under load.

  • Built for higher-demand generator projects, not entry-level demo builds
  • Good fit for G1 Max and other custom turbine or alternator concepts
  • Compact printed form makes installation and repeatable builds easier
  • Custom winding options can support specialized projects
Aries coil product image
ARIES COIL

High-output coil for custom generator systems that need a stronger foundation than typical hobby coils.

  • Wire spec: 16 AWG, 155C
  • Best for: G1 Max and larger custom generator builds
  • Printed in ABS for durable prototype use
Shop Components

What this product is best for

Use the Aries Coil when you need a generator coil for higher-RPM testing, larger charging concepts, or custom magnetic builds where output, durability, and repeatability matter more than low-cost hobby parts.

What builds trust here

  • Performance reference is shown directly on the page instead of hidden behind inquiry
  • Designed around real generator use cases, including the G1 Max platform
  • Custom variations can be discussed if your project needs a different winding setup

Material and performance reference

ITEM ITEM DESCRIPTION QTY EA | SET | FT
ABS, ASA, PETG ABS, ASA, PETG Plastic, 2Kg Spool 1 EA
16 AWG SNS 16 AWG 155C SNS RED - -
3M Tape Yellow Mylar Tape - -
SPECS 1.5VAC, 3.5A. Around 800 RPM is needed to reach that voltage level per coil. Higher RPM produces more voltage. - -

Aries Bobbin Test Results

Recorded electrical output at approximately 800 RPM per coil. Higher RPM produces more voltage.

Recorded electrical test results for the Aries coil bobbin
Wire AWG (155C SNS) Number of Turns Current Voltage RPM
16 AWG 120 turns 3.5 A 1.45 VAC 800
17 AWG 145 turns 2.4 A 1.85 VAC 800
18 AWG 180 turns 2.1 A 2.15 VAC 800
19 AWG 200 turns 1.8 A 2.65 VAC 800
20 AWG 240 turns 1.6 A 2.90 VAC 800
21 AWG 300 turns 1.2 A 3.10 VAC 800
22 AWG 350 turns 0.9 A 3.75 VAC 800

Item

This coil is made for the G1 Max Generator, the larger follow-up to the GEN-1 project. If you need a custom variation for your own turbine or generator concept, use the contact page to ask about winding, bobbin, or design options.

Need a custom version?

If the Aries Coil is close to what you need but not exact, Nexus Magnetic can discuss custom winding specifications, bobbin changes, and prototype-focused magnetic components for your build.
